Mechanism Generator 3.0

21 March, 2012 (01:20) | Linkage Animations | By: Prof. McCarthy

Our Mechanism Generator 3.0 software reads a SolidWorks sketch of a planar 3R chain that reaches five task positions and computes a set of Watt 1 six-bar linkages that approximate movement through the task positions within specified tolerances. An animation previewer shows how each linkage moves. Select one and MechGen 3 generates a solid model of the linkage.

YouTube Preview Image
This is more excellent work from the team of Alex Arredondo and Kastubh Sonawale.

**Update: This video has been revised to provide a preview at the beginning that shows the six-bar linkage that is designed using MechGen 3.
