Folding movement for wings for the Icon A5

26 December, 2011 (22:49) | Linkage Animations, Student Projects | By: Prof. McCarthy

This spherical four-bar linkage concept by Kaustubh Sonawale guides the wings of the Icon A5 in the movement shown in the animation.

YouTube Preview Image

Spherical linkage concept to fold a wing

26 December, 2011 (22:38) | Linkage Animations, Student Projects | By: Prof. McCarthy

This is a spherical four-bar linkage concept by Kaustubh Sonawale designed to fold the wings of an Icon A5 small aircraft.

YouTube Preview Image

Spare tire deployment linkage

26 December, 2011 (22:27) | Linkage Animations, Student Projects | By: Prof. McCarthy

Kaustubh Sonawale designed this four-bar linkage to move a truck spare tire from a stowed position to the deployed position.

YouTube Preview Image

Happy Holidays and Have a Great New Year

24 December, 2011 (22:36) | Student Projects | By: Prof. McCarthy

Happy holidays and have a happy new year!

Happy holidays and have a happy new year!

Instruments for Natural Philosophy

13 December, 2011 (14:31) | Engineering Data, Lecture Notes | By: Prof. McCarthy

This site has photographs of a large number of devices used to teach physics. It is fascinating.
Select the link: http://physics.kenyon.edu/EarlyApparatus/index.html
